The CV3524 is a gas filled relay originally designed for use in telephone systems.
The central trigger lead needs to be connected to a high impedance source. Typically 1 M Ohm.
When triggered the anode current of this cold cathode device should lie between 0.5 and 1.5 mA. The anode supply would be of the order of 175 Volts. When conducting the anode volts would be between 70 and 85 Volts.
The thin glass tube envelope is 8 mm in diameter and, excluding the 3 wire leads is 38 mm tall.
This exhibit was last updated on 14 August 2005
